BINOCULAR MICROSCOPE with overhanging stand - Mod. Szx

Microscope with hinged overhanging stand

The stereomicroscopes of the SZX series are instruments designed for laboratory, Goldsmiths, Stone setters and industry applications.

Their optical and mechanical qualities place them at the top of their category and the price/quality ratio is excellent.

6.7x 45x Zoom - Working distance: 110 mm - Possible extension: with 0.5x close-up lens for magnification

Extremely stable, hinged and long overhanging stand for observation of particularly large specimens. Smooth horizontal and vertical movements are ensured and the head can be easily swivelled and tilted for inspection at oblique angles.

Base dimensions: 260×210 mm

Pillar dimensions: Ø32×425 mm

Horizontal arm: 515 mm

Maximum sample height: 440 mm

Swivelling movement: 360°

Tilting movement: 180°

Weight: 18.8 kg
