CARAT SCALE 200 ct/0.001ct

Precision Scale OHAUS

Durable and accurate scale. internal Calibration. Glass draft shield with three sliding doors. Backlit LCD display.

Applications

Basic Weighing, Parts Counting, Percent Weighing, Density Determination

Display

Backlit Liquid Crystal Display (LCD)

Operation

AC adapter (included)

Communication

RS232 interface and Mini-Din port (for connecting auxiliary display)

Construction

Metal base, plastic top housing, removable stainless steel pan, removable glass draftshield or side doors, integrated weigh-below-hook, security bracket, calibration lock and in-use cover

Design Features

User-selectable environmental filters and brightness settings, auto-tare, auto-dim, user-selectable span calibration points, software lockout and reset menu, userselectable communication settings and data print options, user-definable project and user IDs, software overload/underload indicator, stability indicator

SPECIFICATIONS

Maximum Capacity: 40 g/200 ct

Readability: 0.0001 g; 0.001 ct

Pan Size: 3.5 in (90 mm)

Communication: RS232

Dimensions: 321 mm x 274 mm x 209 mm (LxHxW)

Display: LCD with backlight

Internal Calibration: InCal™ - Semi Automatic

In-Use Cover Included

Legal for Trade NO

Linearity : ± 0.0002 g

Net Weight: 10 lb (4.5 kg)

Pan Construction: Stainless Steel

Power: AC Adapter (Included)

Repeatability, typical 0.0001 g

Stabilization Time: 3 s

Tare Range: To capacity by subtraction

Units of Measurement: Milligram; Ounce Troy; Pennyweight; Taiwan Tael; Gram; Grain; Carat; Ounce; Custom

Working Environment: operability guaranteed between 41°F and 104°F; 50°F – 86°F, 80%RH, non-condensing (operability guaranteed between 5°C and 40°C; 10°C – 30°C, 80%RH, non-condensing)
