CARAT SCALE - 800 ct/0.001ct - legal-for-trade

Applications
Basic Weighing, Parts Counting, Percent Weighing, Density Determination

Display
Backlit Liquid Crystal Display (LCD)

Operation
AC adapter (included)

Communication

RS232 interface and Mini-Din port (for connecting auxiliary display)

SPECIFICATIONS

Maximum Capacity: 160 g/800 ct

Readability: 0.0001 g; 0.001 ct

Readability (Certified) 0.001 g; 0.01 ct

Pan Size: 3.5 in (90 mm)

Communication: RS232

Dimensions: 321 mm x 274 mm x 209 mm (LxHxW)

Display: LCD with backlight

Internal Calibration InCal™ - Semi Automatic

In-Use Cover Included

Legal for Trade YES

Linearity: ± 0.0002 g

Net Weight: 10 lb (4.5 kg)

Pan Construction: Stainless Steel

Power: AC Adapter (Included)

Repeatability, typical: 0.0001 g

Stabilization Time: 3 s

Tare Range: To capacity by subtraction Units of Measurement Milligram; Ounce Troy; Gram; Carat

Working Environment: operability guaranteed between 41°F and 104°F; 50°F – 86°F, 80%RH, non-condensing (operability guaranteed between 5°C and 40°C; 10°C – 30°C, 80%RH, non-condensing)
