CARAT SCALE - 200ct/0.00ct - legal-for-trade

Applications
Basic Weighing, Parts Counting, Percent Weighing, Density Determination

Display
Backlit Liquid Crystal Display (LCD)

Operation
AC adapter (included)

Communication
RS232 interface and Mini-Din port (for connecting auxiliary display)

Construction
Metal base, plastic top housing, removable stainless steel pan, removable glass draftshield or side doors, integrated weigh-below-hook, security bracket, calibration lock and in-use cover

Design Features
User-selectable environmental filters and brightness settings, auto-tare, auto-dim, user-selectable span calibration points, software lockout and reset menu, userselectable communication settings and data print options, user-definable project and user IDs, software overload/underload indicator, stability indicator

SPECIFICATIONS

Maximum Capacity: 40 g/200 ct

Readability: 0.0001 g; 0.001 ct

Pan Size: 3.5 in (90 mm)

Communication: RS232

Dimensions: 321 mm x 274 mm x 209 mm (LxHxW)

Display: LCD with backlight

Internal Calibration: InCal™ - Semi Automatic

In-Use Cover Included

Legal for Trade YES

Linearity : ± 0.0002 g

Net Weight: 10 lb (4.5 kg)

Pan Construction: Stainless Steel

Power: AC Adapter (Included)

Repeatability, typical 0.0001 g

Stabilization Time: 3 s

Tare Range: To capacity by subtraction

Units of Measurement: Milligram; Ounce Troy; Pennyweight; Taiwan Tael; Gram; Grain; Carat; Ounce; Custom

Working Environment: operability guaranteed between 41°F and 104°F; 50°F – 86°F, 80%RH, non-condensing (operability guaranteed between 5°C and 40°C; 10°C – 30°C, 80%RH, non-condensing)
