MICROSCOPE FOR GEMOLOGY - BINOCULAR Nexius 6.7 - 45 x Stereozoom

Microscope for gemology

Binocular stereo microscope with a 1:6.7 zoom objective with 0.67x to 4.5x magnifications, a field of view from 33 mm to 4.9 mm.

Ergonomical designed stand with backwards 0 to 45° tilting arm with 76 mm head holder, suitable for darkfield and brightfield.

Flat darkfield stage with clamp object holder, iris diaphragm and incident illumination.

Clamp object holder can be placed on left or right side

ILLUMINATION : 30 Watt halogen transmitted illumination, adjustable intensity 1 Watt LED, adjustable intensity, or 7 Watt fluorescent incident illumination, intensity not adjustable. Both illuminators can be used simultaneously

220 Volt.

Specifications

EYEPIECES

The microscope is supplied with a pair of HWF 10x/

HEAD

trinocular head with 45° inclined tubes. Both eyepieces with ± 5 diopter adjustments. Interpupillary distance adjustable between 54 mm and 75 mm

OBJECTIVES

The Microcope is supplied with a 1:6.7 zoom objective with 0.67x to 4.5x magnifications, a field of view from 33 mm to 4.9 mm.

Working distance approx. 110 mm.

Auxiliary lenses 0.75x, 1.5x and 2.0x available.

All optics are anti-fungus treated and anti-reflection coated for maximum light throughput

STAND

Ergonomical designed stand with backwards 0 to 45° tilting arm with 76 mm head holder, suitable for darkfield and brightfield. Built-in 100‐240 V power supply

STAGE

Flat darkfield stage with clamp object holder, iris diaphragm and incident illumination. Clamp object holder can be placed on left or right side

ILLUMINATION

30 Watt halogen transmitted illumination, adjustable intensity

1 Watt LED, adjustable intensity, or 7 Watt fluorescent incident illumination, intensity not adjustable Both illuminators can be used simultaneously

PACKAGE

Supplied with power cord, clamp object holder, dust cover, a spare fuse and user manual. All packed in a polystyrene box
