Compact DIGITAL MICROSCOPE

A much-improved version with a bigger screen, better resolution & with HDMI & USB ports.

Features :

1) Ideal for taking full pictures of Rings, Earrings & smaller Jewelry pieces as well as Diamonds & Gemstones in true color.

2) Great for initial use of Gemology, ideal for beginners. It comes with a small disk, which turns the base into Darkfield/Brightfield function.

3) Adjustable Lighting: Diffused lights from top & bottom, adjustable by the control wheel.

4) Multi-Level Magnifications: Gemax Pro-II, comes with height adjustment knobs from low to high, so the customer can achieve overall observation to tiny details of the object while scrolling it up & down.

5) Improved & Bigger screen (7″) with a new microchip to get true colors & crisp image of stones & jewelry.

6) Take high-resolution pictures at any time with the ‘Camera’ button up to 12m & videos in 1080P/720P.

7) Occupied with ” Gemax Protable Capture Pro II ” for measurement & other options.

8) Many useful accessories included,

i) C-Clamp: To read Laser Inscription on loose Diamonds & Stones.

ii) R-Clamp: Ring Holder to read Laser Inscription on Rings, Earrings & stud Jewelry.

iii) Microscope Tweezer: A professional wired Tweezer for inspecting loose Diamonds & Gems.

iv) Assorting Tray: A acrylic tray, with multi-size grooved to suits smaller to bigger stones. Great for color match and pairing.

v) H&A Viewer: A very useful attachment to see Hearts & Arrow cuts in diamonds & to analyze the cutting.

vi) Ring Clips: Provides a hands-free quality check/inspection.

vii) Background colour paper Set: 8 different colour paper set, to change the background while taking pictures or videos.

viii) Gooseneck LED Light: An additional USB light source for more brightness.

Technical data

LCD display: 7″ IPS

Magnification: 10x - 300x, up to 1200x digital

Image resolution: 2 - 12 MP

Video resolution: 1080 P (1920 x 1080), 720 p (1080 x 720)

Focus range: 5 - 70 mm, manually adjustable

External output: Via HDMI / TV / USB

Operation: Via built-in rechargeable battery or AC adapter

LCD menu in 9 languages (English, Spanish, French, German, Italian, Portuguese, Japanese, basic and traditional Chinese) Certifications: CE, FCC approval, RoHS compliance
