Motic Stereo Microscope

Motic Stereo Microscope

Optical zoom bench-top stereomicroscope designed for stereoscopic observation of solid samples and for educational or laboratory activities. It is part of the Motic SMZ-140 series, known for its versatility, reliable optical quality, and modular configurations.

Main technical features

Optics and observation

• Optical system: Greenough (stereo zoom) — sharp, three-dimensional images.

• Head: Binocular, inclined at 45° and rotatable 360° for comfortable observation.

• Eyepieces: WF10X/20 mm with diopter adjustment.

• Optical zoom: 4:1 ratio with magnification range from 1x to 4x (typical total magnification 10x–40x).

Illumination and stand

• Incident LED illumination (top) with intensity control.

• Transmitted LED illumination (bottom) with intensity control — allows observation of transparent or semi-transparent samples.

• Stand with column and base (dimensions approx. 237 × 170 mm).

• Compact and robust structure, suitable for laboratory benches or educational environments.

Optical performance

• 4:1 zoom → enables smooth transition from wide field view to fine details.

• Typical magnification range: 10×–40×, expandable with additional eyepieces or auxiliary lenses.

Weight and dimensions

• Net weight: 6.2 kg

• Dimensions: 237 × 170 × 335 mm
