MICROSCOPE FOR GEMOLOGY - Trinocular Nexius 6.5-55x

Microscope for gemology

The specialized backwards tilting stand of the NexiusZoom stereo microscopes for gemology applications offers 30W halogen transmitted illumination towards the specimen at oblique angles.

This enables the examination of your gems in perfect darkfield conditions. The stand is available with a 7 W fluorescent incident illumination for brightfield contrast.

Trinocular Head: ideal for digital photo and video recordings (you need an adapter to mount a camera!)

Zoom objectives with 0.65 to 5.5x magnification

Highlights

Designed for gemstone research

Trinocular head

Working Distance: 110mm

Standard HWF 10x eyepieces with 22 mm field of view

Zoom objectives with 0.65 to 5.5x magnification

Ergonomic designed backwards tilting stand

30 Watt halogen transmitted illumination

7W fluorescent incident illumination

Configurations up to 220x magnification

Specifications

EYEPIECES

The microscope is supplied with a pair of HWF 10x/

HEAD

trinocular head with 45° inclined tubes. Both eyepieces with ± 5 diopter adjustments. Interpupillary distance adjustable between 54 mm and 75 mm

OBJECTIVES

The Microcope  is supplied with a 1:8.4 zoom objective with 0.65x to 5.5x magnifications, a field of view from 35.4 mm to 4.2 mm.

Working distance approx. 110 mm.

Standard magnification is 6.5 to 55x

Auxiliary lenses 0.75x, 1.5x and 2.0x available.

All optics are anti-fungus treated and anti-reflection coated for maximum light throughput

STAND

Ergonomical designed stand with backwards 0 to 45° tilting arm with 76 mm head holder, suitable for darkfield and brightfield. Built-in 100‐240 V power supply

STAGE

Flat darkfield stage with clamp object holder, iris diaphragm and incident illumination. Clamp object holder can be placed on left or right side

ILLUMINATION

30 Watt halogen transmitted illumination, adjustable intensity

1 Watt LED, adjustable intensity, or 7 Watt fluorescent incident illumination, intensity not adjustable Both illuminators can be used simultaneously

PACKAGE

Supplied with power cord, clamp object holder, dust cover, a spare fuse and user manual. All packed in a polystyrene box
